| Processor | |
| Supported CPU |
Intel Gen 6/7/8/9 LGA1511 CPU
|
| Mainboard | |
| Chipset |
Intel H311M
|
| Memory | |
| Memory Size |
16 GB
|
| Memory Type |
DDR4 3000/2933/2800/2666 memory* (actual memory data transfer speed depends on processor type and memory module)
|
| Memory Slot |
2 x DDR4 memory slots
|
| Networking & Connectivity | |
| LAN |
Onboard Realtek 8111H Gigabit network card; 1 x M.2 wifi interface
|
| Audio & Microphone | |
| Audio |
Onboard Realtek ALC897 high-fidelity audio independent sound card
|
| Ports | |
| PCI Card Slot |
1 x PCI-E x 16 graphics card slot; 1 x PCI-E x 1 slot
|
| VGA |
1 x DisplayPort display output; 1 x HDMI display output; 1 x VGA display output
|
| Interface |
SATA Interface: 3 x SATA3.0 6Gb/s
M.2 Interface: 1 x M.2 slot, supports 2242/2260/2280 type storage devices |
| Power Connector |
24pin+8pin
|
| USB |
2 x USB 3.0 ports at the rear; 4 x USB 2.0 ports; 1 x USB 3.0 header at the front, 2 USB 3.0 ports can be expanded; 1 x USB 2.0 header, 2 USB 2.0 ports can be expanded
|
| Others | |
| Other Features |
CPU Pins: Intel Core i7/i5/i3/Pentium/Celeron LGA1150 (support Intel 22nm processor)
1 x PS/2 keyboard port; 1 x PS/2 mouse port; 1 x RJ45 network port; 3 x 3.5mm audio ports |
| Physical Specification | |
| Form Factor |
M-ATX
|
| Dimension |
170mm x 220mm
|
| Warranty Information | |
| Warranty |
3 Years
|
